Electron实现桌面端计时器

吐槽

最初技术栈为Vue+Electron+TS，太甜美的难了。。。配置报错问题一大堆，一路报错问AI一路改，长达三个小时把文件改的乱七八糟无法收尾忍痛放弃新开项目

**最后技术栈选择为 **Vue+Electron+Vite+JS ，包管理工具选择为 pnpm

完整代码见github仓库 ......(还没推，因为dist文件太大的原因没办法传，目前还在寻找更合理的推送方案)

主步骤

初始化

创建

1
pnpm create vite Tclick --template vue

依赖

package.json 直享版

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
{
    "name": "clock",
    "private": true,
    "version": "0.0.0",
    "description": "An Timer application.",//描述
    "author": "none <你的邮箱>",//作者
    "homepage": "./",
    "main": "main.js",
    "scripts": {
        "dev": "vite",
        "build": "vite build",
        "serve": "vite preview",
        "electron:dev": "concurrently \"cross-env NODE_ENV=development wait-on http://localhost:5173 && electron .\" \"npm run dev\"",
        "electron:build": "npm run build && electron-builder && node post-build.js",
        "start": "npm run electron:dev"
    },
    "dependencies": {
        "vue": "^3.5.13"
    },
    "devDependencies": {
        "@vitejs/plugin-vue": "^5.2.1",
        "concurrently": "^9.1.2",
        "cross-env": "^7.0.3",
        "electron": "^33.3.1",
        "electron-builder": "^25.1.8",
        "vite": "^6.0.5",
        "vite-plugin-html": "^3.2.2",
        "wait-on": "^8.0.2"
    },
    "build": {
        "productName": "Clock",
        "appId": "com.example.clock",
        "directories": {
            "output": "release"
        },
        "files": [
            "dist/**/*",
            "node_modules/**/*",
            "main.js",
            "preload.js"
        ],
        "mac": {
            "target": "dmg",
            "icon": "dist/installer-icon-256.ico"
        },
        "win": {
            "target": "nsis",
            "icon": "dist/installer-icon-256.ico"
        },
        "linux": {
            "target": "AppImage",
            "icon": "dist/installer-icon-256.ico"
        },
        "nsis": {
            "installerIcon": "./public/installer-icon.ico",//这里的ico是我下的时钟图标，替换软件图标
            "oneClick": false,
            "allowToChangeInstallationDirectory": true
        }
    }
}
1
pnpm install

补充项目结构

public/icon（图标）

main.js（Electron主进程）

preload.js（Electron预加载脚本）

post-build.js（文件操作，生成dist）

核心配置

index.html

1
2
3
4
5
6
7
8
9
10
11
12
13
<!DOCTYPE html>
<html lang="en">
    <head>
        <meta charset="UTF-8" />
        <link rel="icon" type="image/svg+xml" href="./dist/installer-icon.ico" />
        <meta name="viewport" content="width=device-width, initial-scale=1.0" />
        <title>Clock</title>
    </head>
    <body>
        <div id="app"></div>
        <script type="module" src="/src/main.js"></script>
    </body>
</html>

main.js（Electron主进程）

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
const { app, BrowserWindow } = require('electron')
const path = require('path')

function createWindow() {
    const win = new BrowserWindow({
        width: 500,
        height: 210,
        x: 800, // 指定初始 x 坐标
        y: 20, // 指定初始 y 坐标
        webPreferences: {
            preload: path.join(__dirname, 'preload.js'),
            nodeIntegration: false,
            contextIsolation: true,
            // 设置 CSP
            additionalArguments: ['--disable-features=ElectronSandbox'], // 根据需要调整
            webviewTag: false, // 禁止使用 <webview> 标签
            webSecurity: true,
            sandbox: true,
            contentSecurityPolicy: `
        default-src 'self';
        script-src 'self';
        connect-src 'self';
        style-src 'self' 'unsafe-inline'; /* 如果需要内联样式 */
        img-src 'self' data:;
        font-src 'self';
      `,
        },
        title: 'Clock', // 设置窗口标题
        icon: path.join(__dirname, 'dist', 'installer-icon.ico'), // 设置窗口图标
        autoHideMenuBar: true, //自动隐藏菜单栏
        alwaysOnTop: true, // 确保窗口始终在顶部
        // frame: false, // 隐藏窗口边框
        // resizable: false, // 禁止调整窗口大小
        transparent: true, // 使窗口透明
        // skipTaskbar: true, // 跳过任务栏显示
    })

    if (process.env.NODE_ENV === 'development') {
        win.loadURL('http://localhost:5173')
        // win.loadFile('dist/index.html')
    } else {
        win.loadFile(path.resolve(__dirname, 'dist', 'index.html'))
    }
}

app.whenReady().then(() => {
    createWindow()

    app.on('activate', function () {
        if (BrowserWindow.getAllWindows().length === 0) createWindow()
    })
})

// 其他事件监听器...

app.on('window-all-closed', () => {
    if (process.platform !== 'darwin') {
        app.quit()
    }
})

app.on('activate', () => {
    if (BrowserWindow.getAllWindows().length === 0) {
        createWindow()
    }
})

preload.js（Electron预加载脚本）

1
2
3
4
// preload.js
window.addEventListener('DOMContentLoaded', () => {
    // 这里可以添加与DOM交互的代码
})

post-build.js（文件操作，生成dist）

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
const fs = require('fs')
const path = require('path')

const htmlFilePath = path.resolve(__dirname, 'dist', 'index.html')

fs.readFile(htmlFilePath, 'utf8', (err, data) => {
    if (err) {
        return console.log(err)
    }

    const result = data.replace(/<title>.*?<\/title>/, '<title>Clock</title>')

    fs.writeFile(htmlFilePath, result, 'utf8', (err) => {
        if (err) return console.log(err)
    })
})

简陋的组件

App.vue

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
<template>
    <div id="app" class="hide-scrollbar">
        <Main />
    </div>
</template>

<script setup>
    import Main from './components/index.vue'
</script>

<style scoped>
    .hide-scrollbar {
        scrollbar-width: none; /* Firefox */
        -ms-overflow-style: none; /* IE 和 Edge */
    }

    .hide-scrollbar::-webkit-scrollbar {
        display: none;
    }
</style

utils/timeUtils.js

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
export const getFormattedTime = () => {
    const now = new Date();

    // 获取当前时间的小时、分钟和秒数，并确保它们都是两位数
    const padZero = (num) => num.toString().padStart(2, '0');
    const hours = padZero(now.getHours());
    const minutes = padZero(now.getMinutes());
    const seconds = padZero(now.getSeconds());

    return {
        hoursFirstChar: hours[0],
        hoursSecondChar: hours[1],
        minutesFirstChar: minutes[0],
        minutesSecondChar: minutes[1],
        secondsFirstChar: seconds[0],
        secondsSecondChar: seconds[1],
    };
}

components / index.vue

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
<template>
    <div class="layouts">
        <div v-for="(title, index) in titles" :key="index" class="layout">
            <div></div>
            <div class="top">
                <div class="title">{{ title }}</div>
                <div class="btn" @click="start(index)" :disabled="timers[index].isRunning">开始</div>
                <div class="btn" @click="stop(index)" :disabled="!timers[index].isRunning">停止</div>
                <div class="btn" @click="reset(index)" :disabled="timers[index].elapsedTime === 0">重置</div>
            </div>
            <!-- <Flip
                :hours="timers[index].formattedTime.hours"
                :minutes="timers[index].formattedTime.minutes"
                :seconds="timers[index].formattedTime.seconds" /> -->
            <Timer />
        </div>
    </div>
</template>

<script setup>
    import { ref, computed } from 'vue'
    import Flip from './Flip/index.vue'
    import Timer from './Timer/index.vue'

    const titles = ['学习时长', '英语时长', '看书时长', '博客时长']
    const timers = ref([])

    for (let i = 0; i < 4; i++) {
        timers.value.push({
            startTime: null,
            elapsedTime: 0,
            isRunning: false,
            formattedTime: { hours: '00', minutes: '00', seconds: '00' }
        })
    }

    const start = (index) => {
        if (!timers.value[index].isRunning) {
            timers.value[index].startTime = Date.now() - (timers.value[index].startTime ? timers.value[index].startTime : 0)
            timers.value[index].isRunning = true
            updateElapsedTime(index)
        }
    }

    const stop = (index) => {
        timers.value[index].isRunning = false
    }

    const reset = (index) => {
        timers.value[index].startTime = null
        timers.value[index].elapsedTime = 0
        timers.value[index].isRunning = false
    }

    const updateElapsedTime = (index) => {
        if (timers.value[index].isRunning) {
            timers.value[index].elapsedTime = Math.floor((Date.now() - timers.value[index].startTime) / 1000)
            updateFormattedTime(index)
            setTimeout(() => updateElapsedTime(index), 1000)
        }
    }

    const updateFormattedTime = (index) => {
        const hours = Math.floor(timers.value[index].elapsedTime / 3600).toString().padStart(2, '0')
        const minutes = Math.floor((timers.value[index].elapsedTime % 3600) / 60).toString().padStart(2, '0')
        const seconds = (timers.value[index].elapsedTime % 60).toString().padStart(2, '0')
        timers.value[index].formattedTime = { hours, minutes, seconds }
    }
</script>

<style scoped>
    .layouts {
        display: flex;
        flex-direction: row;
        gap: 20px;
    }

    .layout {
        display: flex;
        flex-direction: column;
        align-items: center;
        width: 25%;
    }

    .layout .top {
        display: flex;
        justify-content: space-between;
        align-items: center;
        width: 100%;
        background: #fff;
        border-radius: 20px;
        padding: 10px;
        box-sizing: border-box;
    }

    .layout .top .title {
        font-size: 20px;
        font-weight: 700;
        color: #333;
        margin-right: auto;
    }

    .layout .top .btn {
        display: flex;
        justify-content: center;
        align-items: center;
        width: 50px;
        height: 24px;
        border-radius: 10px;
        border: 1px solid #333;
        font-size: 14px;
        font-weight: 700;
        color: #333;
        padding: 0px 3px;
        cursor: pointer;
    }

    .layout .top .btn:hover {
        background: #333;
        color: #fff;
    }
</style>

components / Flip / index.vue

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
<template>
    <div class="clock">
        <!-- 小时 -->
        <div class="flip">
            <div class="digital" :data-number="hoursFirstChar">{{ hoursFirstChar }}</div>
        </div>
        <div class="flip">
            <div class="digital" :data-number="hoursSecondChar">{{ hoursSecondChar }}</div>
        </div>
        <em class="divider">:</em>

        <!-- 分钟 -->
        <div class="flip">
            <div class="digital" :data-number="minutesFirstChar">{{ minutesFirstChar }}</div>
        </div>
        <div class="flip">
            <div class="digital" :data-number="minutesSecondChar">{{ minutesSecondChar }}</div>
        </div>
        <em class="divider">:</em>

        <!-- 秒 -->
        <div class="flip">
            <div class="digital" :data-number="secondsFirstChar">{{ secondsFirstChar }}</div>
        </div>
        <div class="flip">
            <div class="digital" :data-number="secondsSecondChar">{{ secondsSecondChar }}</div>
        </div>
    </div>
</template>

<script setup>
    import { ref, onMounted, watch } from 'vue';
    import { getFormattedTime } from '../../utils/timeUtils'; // 确保路径正确

    const hoursFirstChar = ref('');
    const hoursSecondChar = ref('');
    const minutesFirstChar = ref('');
    const minutesSecondChar = ref('');
    const secondsFirstChar = ref('');
    const secondsSecondChar = ref('');

    const updateTime = () => {
        const time = getFormattedTime();
        hoursFirstChar.value = time.hoursFirstChar;
        hoursSecondChar.value = time.hoursSecondChar;
        minutesFirstChar.value = time.minutesFirstChar;
        minutesSecondChar.value = time.minutesSecondChar;
        secondsFirstChar.value = time.secondsFirstChar;
        secondsSecondChar.value = time.secondsSecondChar;
    };

    onMounted(() => {
        updateTime(); // 初始化时更新时间
        setInterval(updateTime, 1000); // 每秒更新一次时间
    });
</script>

<style scoped>
    body {
        display: flex;
        justify-content: center;
        align-items: center;
        height: 100vh;
        width: 100vw;
        background-color: #2c3e50; /* 添加背景色以便于查看 */
    }

    .clock {
        display: flex;
    }

    /* 时钟的分隔 */
    .clock .divider {
        font-size: 30px;
        line-height: 60px;
        font-style: normal;
        color: rgb(255, 255, 255); /* 更改为白色以便于查看 */
        margin: 0 5px;
    }

    /* 时钟的卡片 */
    .clock .flip {
        position: relative;
        width: 40px; /* 稍微增加宽度以确保数字完全显示 */
        height: 60px; /* 增加高度以确保数字完全显示 */
        margin: 2px;
        font-size: 48px; /* 增加字体大小以便于查看 */
        font-weight: 700;
        line-height: 60px; /* 确保文本垂直居中 */
        text-align: center;
        background: rgb(46, 45, 45);
        border: 1px solid rgb(34, 33, 33);
        border-radius: 10px;
        box-shadow: 0 0 6px rgba(54, 54, 54, 0.5);
    }

    /* 时钟上的数字 */
    .clock .flip .digital {
        position: absolute;
        top: 0;
        left: 0;
        right: 0;
        bottom: 0;
        color: white; /* 数字颜色为白色 */
        background: transparent; /* 背景透明 */
        border-radius: 10px;
        display: flex;
        align-items: center;
        justify-content: center;
    }
</style>

components / Timer / index.vue

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
<template>
    <div>
        <h1>{{ formattedTime }}</h1>
        <button @click="start" :disabled="isRunning">开始</button>
        <button @click="stop" :disabled="!isRunning">停止</button>
        <button @click="reset" :disabled="elapsedTime === 0">重置</button>
    </div>
</template>

<script setup>
    import { ref, computed, onMounted, onUnmounted } from 'vue'

    const startTime = ref(null)
    const elapsedTime = ref(0)
    const isRunning = ref(false)

    const formattedTime = computed(() => {
        const hours = Math.floor(elapsedTime.value / 3600).toString().padStart(2, '0')
        const minutes = Math.floor((elapsedTime.value % 3600) / 60).toString().padStart(2, '0')
        const seconds = (elapsedTime.value % 60).toString().padStart(2, '0')
        return `${hours}:${minutes}:${seconds}`
    })

    let intervalId = null

    function start() {
        if (!isRunning.value) {
            startTime.value = Date.now() - (startTime.value ? startTime.value : 0)
            isRunning.value = true
            intervalId = setInterval(updateElapsedTime, 1000)
        }
    }

    function stop() {
        clearInterval(intervalId)
        isRunning.value = false
    }

    function reset() {
        clearInterval(intervalId)
        startTime.value = null
        elapsedTime.value = 0
        isRunning.value = false
    }

    function updateElapsedTime() {
        elapsedTime.value = Math.floor((Date.now() - startTime.value) / 1000)
    }

    onMounted(() => {
        document.addEventListener('visibilitychange', handleVisibilityChange)
    })

    onUnmounted(() => {
        document.removeEventListener('visibilitychange', handleVisibilityChange)
        clearInterval(intervalId)
    })

    function handleVisibilityChange() {
        if (document.visibilityState === 'hidden') {
            if (isRunning.value) {
                stop()
            }
        } else if (document.visibilityState === 'visible') {
            if (isRunning.value) {
                start()
            }
        }
    }
</script>

启动项目

1
pnpm run build

网页端开发环境

1
pnpm run dev

桌面端开发环境

1
pnpm run start

.exe文件生成位置

release文件夹中的 Setup.exe（文件有70多m!!!不理解）

TODO

1.桌面软件图标还是Electron的，需要修改为下好的ico

2.git大文件提交问题（可能是需要改动gitignore？没有接触过）

3.第一版Vue+Electron+TS项目提到过自动发布版本工作流，还有检测标签啥的，还没弄懂这周探索一下，没记错的话github主页的贪吃蛇好像也和这个有关系

4.简单UI排布

5.交互功能：用户可自行添加多个计时器，且独立计时

6.考虑到挂后台会有计时误差，添加新的计时逻辑（begin记录时间戳，从后台调出时通过时间戳相减更新时间）
